Efficient 4WD Wheel Loader

Neat compact build conserves space

Low‑set gravity boosts stability

Narrow turn circle suits confined zones

Robust power tackles heavy duties

Contact Now E-Mail Telephone WhatsApp

Overview
Technical data
Configurations
Attachments

Product Introduction

Engineered for extreme durability, the W1160 is purpose-built to withstand complex, harsh workplace conditions and continuous high-load operations, maintaining steady and dependable output amid rigorous on-site challenges. Fitted with premium Rexroth hydraulic parts renowned for rugged endurance and precise operation, paired with a state-of-the-art hydrostatic drive system, the unit delivers steady high power output to handle strenuous workloads effortlessly. It also features ultra-sensitive, instant-reaction load adjustment that adapts dynamically to diverse operational needs, guaranteeing seamless, high-efficiency performance in all working scenarios.Boasting outstanding versatility for multipurpose use, this machine excels in a wide array of application scenarios. It is ideal for large scale construction waste cleanup, professional forest land clearance and routine maintenance, as well as heavy-duty bulk material loading and transport for farming and industrial operations. Its core competitive edge lies in its stable, fail-proof operational consistency. It works reliably even under the toughest outdoor construction, forestry and agricultural working conditions, where standard machinery is unable to operate stably and efficiently.

Efficient 4WD Wheel Loader

Product Specifications

Engine Rated Power (kw/HP)：18.4kW/2800rpm

Operating Weight (kg):1850 kg

Tipping Load with Bucket--Machine Straight (kg):850 kg

Bucket Pivot Point :520

Learn More

Applications

Feed Conveying Loader for European Equestrian Grounds

Built to serve European horse farms, this loader handles hay, grain and forage transportation reliably.Its compact design suits narrow stable passages and open pastures, operating quietly to avoid startling horses.It optimizes daily feeding workflows, reduces manual work and enhances stable maintenance efficiency.

Efficient 4WD Wheel Loader

Narrow Row Olive Transport Loader for European Groves

Engineered for closely planted European olive orchards, this loader safely conveys freshly collected olives.Its slim profile moves smoothly between tree lines without damaging trunks or fruits.Stable and easy‑to‑operate, it accelerates seasonal olive harvest logistics and eases farm workload.

Efficient 4WD Wheel Loader

Technical Data for W1160 Compact Loader
Engine
Brand/Model	Perkins 403J-11 or Kubota D1105
Type:	3 Cylinders, Water Cooling
Power Output	18.4kW/2800rpm
Displacement	1.13 L
Emissios Standard：	Euro Stage V
Drive System
Type of Drive	Hydrostatic
Gear Shift	Electric, Continuously Variable Transmissioin (CVT)
Travel Speed	0-20 km/h
Electrical System
Operating Voltage	12 V
Battery Capacity	60 Ah
Alternator Rating	40 A
Hydraulic System
Max.Drive Hydraulics Work Pressure	300 bar
Max. Drive Hydraulics Discharge Volume	84 l/min
Max. Work Hydraulics Work Pressure	180 bar
Max. Work Hydraulics Discharge Volume	32 l/min
Boom Lifting Time	3.1 s
Automatic Levelling Function	yes
Weight
Operating Weight	1850 kg
Tipping Load with Bucket--Machine Straight:	850 kg
Tipping Load with Bucket--Machine Pivoted:	550 kg
Bucket Capacity	0.28 m3
Max.Lifting Force	1100 kg
Refilling Capacity
Fuel Tank (L)	26 L
Hydulic Oil Tank (L)	40 L
Engine Oil (L)	4 L
Coolant (L)	12 L
Brake System
Operating Brake	Transmission Drum Brake
Parking Brake	Operating and Parking Brake in the Drive Train
Tyre Size	31x15.5-15
Machine Dimension (mm)
Overall Length with Bucket	3895
Overall Length without Bucket	3065
Bucket Pivot Point to the Centre of Axle	520
Wheel Base	1522
Rear Overhang	950
Height to the Roof of Canopy	2210
Seat Height	1200
Working Range (mm)
Overall Working Height	3180
Max. Lifting Height	2740
Load-Over Height	2385
Dumping Height	1900
Digging Depth	120
Overall Width	1300
Wheel Track	910
Ground Clearance	221
Max. Turning Radius	2435
Outter Turning Radius	2220
Inner Turning Radius	880
Articulation Angle	51°
Roll Back Angle at Max. Lifting Height	52°
Dumping Angle	35°

	1.Engine: KUBOTA D1105 (Euro 5), Optional: Perkins
	2.Hydraulic System: German Rexroth pump, Gerotor motor, domestic valves; 1 pump + 2 motors, Inching function
	3.Boom Function: Floating function (optional)
	4.Control System: Electronic control levers with integrated forward/reverse buttons 5.(High/Low speed optional)
	6.Brake Inching Function (optional)
	7.Seat Sensor (optional)
	8.Lights: Turn signals, LED work lights
	9.EU-standard Hydraulic Quick Coupler,Quick change, customization supported
	10.Tires: 31.5*15-15.5
	11.Canopy: EPS,detachable, foldable, and closable.

1. Feed Blade Main Application Scenarios Are you looking to spread fermented silage, concentrated feed mixes and other livestock feeds uniformly along farm feeding troughs? This feed‑pushing attachment streamlines daily animal feeding workflows and greatly raises operational productivity. Core Functions Hydraulic power allows the blade to be adjusted over a broad angle range for full coverage of feeding areas. It pivots side‑to‑side to change pushing paths, readily reaching every part of feeding zones without any uncovered spots.
Parameter	Value Range
Width	1800 mm - 2200 mm
Max. Adjustable Angle	70°
Weight	225 kg
		2. Bale Fork Main Application Scenarios Want a practical solution to hoist and pile round and square hay‑straw bales without adding extra accessories? This purpose‑built bale attachment quickly attaches to regular pallet fork bases, supporting smooth, labor‑saving farm work. Core Functions It fastens rapidly to all standard pallet fork assemblies. Two sharpened prongs securely pierce into bales and keep them stable, making farm‑based bale hauling and stacking far more straightforward.
		Parameter	Value Range
		Width	1130 mm
		Weight	65 kg
3. Round Bale Tong Main Application Scenarios If you hope to move and stock wrapped round hay bales while protecting their plastic wrapping from scratches and avoiding extrusion of the inner forage, this professional bale handling accessory is your ideal choice. It delivers tender yet highly efficient handling for wrapped round feed bales widely adopted in animal husbandry production. Core Functions The equipment features stable clamping performance that avoids any exterior damage to bales, perfectly retaining the completeness of each round bale’s original wrapping film. It effectively safeguards the inherent quality of reserved forage and locks up its nutrients, greatly prolonging the feed’s usable storage time.
Parameter	Value Range
Width	1400mm
Weight	158 kg
		4. Fence Mower Main Application Scenarios Drained of laborious, repetitive hand trimming and weed clearing around fence posts on farmland, pastures and urban green landscapes? This professional fence mower simplifies fence perimeter upkeep work, delivering comprehensive, uniform cutting results to keep the ground surrounding fence posts clean and well-groomed. Core Functions It achieves neat, finished trimming around every fence post, removing the need for exhausting manual work. Equipped with hydraulic mode switching capability between travel and working states, the unit allows full in-cab operation, requiring no external stepping down or manual mode adjustment during use.
		Parameter	Value Range
		Weight	220 kg
5. Double-blade Mowing Unit Main Application Scenarios Wish to polish and perfect the look of hedges in private gardens or urban green belts? This dual-blade trimmer attachment effortlessly handles side trimming and multi-angle cutting work, reshaping overgrown, messy hedges into tidy, polished landscape features. Core Functions Designed with three adjustable cutting positions for versatile operation, this tool performs exceptionally well on hedge side trimming. It consistently delivers clean, polished trimming results, helping hedges retain a neat, professional finish after every use.
Parameter	Value Range
Width	1500 mm
Weight	200 kg
